Gimbal Controller
fabrication / arduino / 3D printing
2022 — 2023
fabrication / arduino / 3D printing
2022 — 2023
Worked in partnership with Cosm.
The prototype below is a playful exploration on the ergonomics of a hand and its relationship to a digital display. In conjunction with Cosm’s innovative display technology at their newly established venues, this prototype was developed as an interactive device for large-scale audience.
![]()
![](https://freight.cargo.site/t/original/i/caa93b3d751a8358266ff8e18d2ba138b8a7f4ceee47d3317f47f79a3e8a2a08/IMG_3496_2-2.png)
Gimbal Controller
Materials: 3D printed parts, potentiometers, arduino, large button
Gimbal Controller is a real world application of how necessarily tactility is to human interaction. The interactive device is designed to be intuitive yet exporable, with the mindset that the audience will only have a few moments to learn how to use the device. The simple controls move the audience in a x,y and even z pattern on the screen by rotating the inner and outer disks. The spherical nature of the device is meant to mimic the latitude and longitude of the curved digital display.
![](https://freight.cargo.site/t/original/i/0473b150990ba8a1cfd0b15860d04f0a951094e49a5f509025dd4e2ee5a807f2/cosmdomeeditforportfolio-1.png)
Cosm Venue
Multitiered theater with viewing and interactive entertainment.
Multitiered theater with viewing and interactive entertainment.
![](https://freight.cargo.site/t/original/i/41aa7625e434f383b7fc1d3b6242a6235ee502cda820465770688944f7e5d98f/handandchair.png)
Interactive device inlaid into arm of chair, each audience
member would have their own device.
member would have their own device.
Developed an interactive game to demonstrate
the X, Y, Z movement of the device on a screen.
the X, Y, Z movement of the device on a screen.
![](https://freight.cargo.site/t/original/i/63fd9588f4d74d1b0985b4535496d1b132212b5e147472e136325cf3a08f9374/device-tech-drawing.png)
Technical drawings of device
3D printed prototype
3D printed prototype
